RPET Clear Rigid Sheet For Clamshell Thermoforming
RPET Clear Rigid Sheet For Clamshell Thermoforming is a sustainable, high-clarity packaging material manufactured from post-consumer recycled PET (RPET) content. This rigid sheet is specifically engineered for thermoforming applications, delivering the optical clarity and mechanical performance of virgin PET while significantly reducing environmental impact. The sheet is ideal for producing durable, transparent clamshell packaging for consumer goods, electronics, hardware, and retail products.
The use of RPET in this sheet does not compromise quality-advanced recycling and decontamination processes ensure the material meets food-contact and consumer safety standards. The sheet offers excellent gloss, low haze, and consistent formability, making it a drop-in replacement for virgin PET on existing thermoforming lines.
Key Sustainability Credentials:
Contains up to 100% post-consumer recycled content (grade dependent)
Reduces carbon footprint by 30–50% compared to virgin PET
100% recyclable (#1 PET) at end of life
FDA-compliant for food contact (specific RPET grades)
Applications: Clamshell packaging for electronics, toys, hardware, cosmetics, fresh produce, and bakery items.
▸ Technical Specifications
| Parameter | Specification |
|---|---|
| Material | RPET (post-consumer recycled PET) |
| Recycled Content | Up to 100% (customizable) |
| Thickness Range | 0.20mm – 0.80mm (200–800µm) |
| Width Range | 100–1200 mm (slit to order) |
| Haze | <5% |
| Light Transmission | >85% |
| Gloss (60°) | ≥95 GU |
| Density | 1.35 g/cm³ |
| Tensile Strength (MD) | ≥48 MPa |
| Elongation at Break (MD) | ≥280% |
| E-modulus (MD) | ≥2.0 GPa |
| Impact Strength (Izod) | ≥4.5 kJ/m² |
| Thermoforming Temperature | 100–125°C |
| Heat Deflection Temperature | 65°C |
| Maximum Service Temperature | 60°C |
| Food Contact Compliance | FDA 21 CFR (recycled PET grades) |
| Recycling Code | #1 PET |
Key Features – Sustainable Clamshell Performance
High Recycled Content – Up to 100% RPET reduces reliance on virgin petroleum-based plastics. Supports corporate sustainability targets and retailer packaging requirements.
Crystal Clarity – Haze <5% ensures product visibility-essential for retail packaging where consumers need to see the product before purchase.
Excellent Thermoformability – Performs identically to virgin PET on standard thermoforming equipment. No machine modifications required.
Consistent Thickness Profile – ±3% thickness tolerance ensures uniform heating and consistent wall thickness across formed parts.
Strong Hinge Durability – Formulated for clamshell applications-resists stress whitening at the hinge line, maintaining appearance after repeated opening.
Food Contact Compliant – FDA-approved RPET grades available for direct food contact applications (produce, bakery, confectionery).
Print-Ready Surface – Corona-treated surface accepts high-quality printing for branding and product information.
Impact Resistant – Protects contents during shipping and handling-reduces product damage claims.
Applications – Clamshell Focus
| Product Category | Specific Examples | Why RPET Clamshell |
|---|---|---|
| Consumer Electronics | Headphones, chargers, cables, small accessories | Clarity shows product; rigid protection; sustainable branding |
| Toys & Stationery | Action figures, craft kits, pens, erasers | Durable hinge for repeated opening; clear visibility |
| Hardware & Tools | Drill bits, fasteners, small parts | Impact resistance; puncture protection |
| Fresh Produce | Berries, cherry tomatoes, herbs | Food contact compliant; clarity shows freshness |
| Bakery & Confectionery | Cupcakes, cookies, chocolates | Premium appearance; sustainable packaging claim |
| Cosmetics & Personal Care | Lip balms, compacts, travel sizes | High gloss for luxury appeal; recyclable |
2, Blister packaging: Toys, accessories, batteries, commodities.
5, Printing: Silk Printing, UV Offset Printing
8, Plastic barrier: For preventing face to face talking to stop virus approaching.
Quality Assurance – RPET Specifics
In-Process Controls:
Recycled content verification – FTIR and supplier certification
Thickness profile – online beta gauge (±3%)
Haze measurement – inline hazemeter (<5%)
Visual inspection – 100% surface scan for contaminants
Finished Product Testing (Per Batch):
| Test | Method | Specification |
|---|---|---|
| Haze | ASTM D1003 | <5% |
| Gloss (60°) | ASTM D2457 | ≥95 GU |
| Thickness | Micrometer | ±3% |
| Drop Dart Impact | In-house | No break at 1m |
| Hinge Flex | In-house | No whitening after 500 cycles |
Certificate of Analysis Includes:
Recycled content percentage
Haze and gloss values
Thickness profile
Impact test result
Food contact compliance (if applicable)
FAQ – RPET Clamshell Focus
Q1: What percentage of recycled content does this sheet contain?
We offer grades from 30% to 100% post-consumer recycled content. Specify your target percentage at order. Higher recycled content may slightly affect clarity-we recommend testing a sample first.
Q2: Is RPET as clear as virgin PET?
Yes-with advanced recycling technology, high-quality RPET achieves clarity comparable to virgin PET. Haze <5% is achievable with our optimized formulation.
Q3: Can RPET be used for food contact packaging?
Yes-FDA-approved RPET grades are available for direct food contact. The recycling process ensures contaminants are removed to safe levels.
Q4: Does RPET affect thermoforming performance?
No-RPET behaves identically to virgin PET on thermoforming lines. No machine modifications needed.
Q5: Is the sheet recyclable after use?
Yes-RPET clamshells are #1 PET and widely accepted in municipal recycling programs.
Q6: What is the shelf life of the sheet itself?
18 months when stored at 15–25°C, <60% RH, away from direct sunlight.
Q7: What is the minimum order for a trial?
Sample sheets (10 A4): free + courier. Sample roll (50kg): $250 + shipping. Trial roll (200kg): 7 working days. Commercial MOQ: 500kg.
RPET Clear Rigid Sheet For Clamshell Thermoforming – the sustainable choice for brands seeking to reduce environmental impact without compromising packaging performance or visual quality. Contact us for a sample and sustainability data sheet.
